Connecting the wires - CCTV Installation Tutorial

SAED CCTV Installation Training - Connecting the wires

Steps to connect the BNC port: The video cable is connected via a BNC port. Remove about 1.5cm of outer covering of the video cable which should now expose the braids. Slide the crimping barrel onto the cable with wider diameter facing towards the end of the cable. Now remove the white insulator covering the innermost cable. Now insert this exposed cables into the BNC port and screw the crimping barrel. This makes a secure connection. Connect the DVR output port to the screen on which you want the video feed.
